| 起源の場所: | 中国 |
| ブランド名: | IONPURE |
| 証明: | CE |
| モデル番号: | IP-LXM24Z-5 |
| ドキュメント: | fgwater-ionpure-lxz-ds.pdf |
| 最小注文数量: | 1 PC |
|---|---|
| 価格: | 交渉可能 |
| パッケージの詳細: | 標準輸出梱包 |
| 受渡し時間: | 5〜8 営業日 |
| 支払条件: | T/T、ウェスタンユニオン |
| 供給の能力: | 月額60000ユニット |
| 24Z-5最小流量M3/HR（GPM）: | 1.36 (6.0) | 24Z-5設計流量M3/HR（GPM）: | 2.8-4.2 (12.5-18.8) |
|---|---|---|---|
| 24Z-5出荷重量kg（lbs）**: | 115 (254) | 24Z-5動作重量kg（lbs）: | 92 (103) |
| モジュール復元: | 90~95% | スタック の 利点: | 流量も幅広く 運用コストも低く 安定して信頼性の高い 高純度な水を供給します |
| スタック直流電圧: | 0・400 | スタック DC アンペレージ: | 1.0 ¥60 |
| 製品の用途: | バイオ医薬品産業 | ||
| ハイライト: | Ionpure CEDI LX-Z EDI module,EDI module for biopharmaceutical industry,IP-LXM24Z-5 EDI module with warranty |
||
| Attribute | Value |
|---|---|
| 24Z-5 Minimum Flow Rate m3/hr (gpm) | 1.36 (6.0) |
| 24Z-5 Design Flow Rate m3/hr (gpm) | 2.8-4.2 (12.5-18.8) |
| 24Z-5 Shipping Weight kg (lbs) | 115 (254) |
| 24Z-5 Operating Weight kg (lbs) | 92 (103) |
| Module Recovery | 90–95% |
| Stack Advantages | Wide Range Of Flow, Low Operating Costs, Providing Stable And Reliable High Purity Water |
| Stack DC Voltage | 0–400 |
| Stack DC Amperage | 1.0–6.0 |
| Product Application | Biopharmaceutical Industry |
The EDI membrane block removes ions through built-in ion exchange resin (Na+ represents cations and C1- represents anions). The system consists of:
CE mark certified, each module undergoes strict factory testing to meet industry standards. Manufactured under ISO 9001 and ISO 14000 quality and environmental management systems.
Install indoors away from direct sunlight. Ambient temperature must not exceed 113°F (45°C) for stable operation and extended service life.
| Parameter | Value |
|---|---|
| Recovery | 90-95% |
| DC Voltage | 0-400 |
| DC Amperage | 1.0-6.0 |
| Product Resistivity | Minimum Flow > 17 MW-cm*† Maximum Flow > 7 MW-cm*† |
| Silica (SiO2) Removal | 90-99%, depending on feed conditions |
| Parameter | Requirement |
|---|---|
| Conductivity (including CO2 and Silica) | < 40 μS/cm |
| Temperature | 5-45˚C (41-113˚F) |
| Inlet Pressure | 1.4-6.9 bar (20-100 psig) |
| Total Chlorine (as Cl2) | < 0.05 ppm |
| Total Hardness (as CaCO3) | < 1.0 ppm |
FG Water Technologies (www.fgwater.com) is part of Wuxi Fenigal Science and Technology Co. Ltd., specializing in water treatment equipment design, manufacturing, and international shipment. Our products include:
We serve industries worldwide including food & beverage, pharmaceutical, chemical, power, and wastewater treatment.
