| 起源の場所: | 中国 |
| ブランド名: | VEOLIA |
| 証明: | CE |
| モデル番号: | mk-3miniht |
| ドキュメント: | Veolia EDI catalog.pdf |
| 最小注文数量: | 1 PC |
|---|---|
| 価格: | 交渉可能 |
| パッケージの詳細: | 標準輸出梱包 |
| 受渡し時間: | 5-8勤務日 |
| 支払条件: | T/T、ウェスタンユニオン |
| 供給の能力: | 月額60000ユニット |
| このmdoelのミニフローレート範囲: | 0.5–1.6 m3 /h（2.2–7.0 gpm） | このモデルの配送重量: | 57 kg（126ポンド） |
|---|---|---|---|
| このモデルのminiht寸法（幅x高さx深さ）: | 30 cm x 61 cm x 29 cm | miniht抵抗率: | ≥10（医薬品）または≥16moM-cm（産業 |
| ナトリウム: | ≤3ppb（産業） | 最大消毒温度: | 85ºC（185ºF） |
| 最大消毒入口圧力: | 2.1バー（30 psi） | 応用: | 製薬用浄水 |
| Flow Rate Range | 0.5–1.6 m³/h (2.2–7.0 gpm) |
| Shipping Weight | 57 kg (126 lbs) |
| Dimensions | 30 cm x 61 cm x 29 cm |
| Resistivity | ≥ 10 MOhm-cm (Pharmaceutical) or ≥ 16 MOhm-cm (Industrial) |
| Maximum Sanitization Temperature | 85ºC (185ºF) |
Maintains resistivity above 18.2 MΩ*cm with 22% energy reduction compared to traditional EDI equipment. Achieves recovery rates exceeding 90% even with high-hardness raw water.
| Parameter | Value |
|---|---|
| Inlet Pressure | 6.9 bar (100 psi) |
| Max Temperature | 40°C (104°F) |
| Pressure Drop | 1.4-2.8 bar (20-40 psi) |
| Recovery Rate | Up to 93% |
| Conductivity | <117 µS/cm |
| pH Range | 4-11 |
Ideal for water for injection, pharmaceutical purified water, and laboratory purified water systems. Complies with USP, EP, and other pharmacopeia standards.
For more information about our EDI technology and application cases, visit FG Water Technologies.
FG Water Technologies is a high-tech entity specializing in water treatment equipment design, manufacturing, and international shipment. Our products serve various industries including pharmaceutical, food and beverage, chemical, and power.
