詳細製品概要

2880モジュールフロー範囲:	3.1 - 9.3 m3 /hr	2880モジュール膜領域:	77m²
2880モジュール公称細孔直径:	0.03 µm	2880モジュールコア素材:	PVDF
このモデルの2880モジュールろ液束:	40-120	このモデルの直径:	8インチ
製品フロー方向設定:	外部圧力構造、行き止まりのろ過	製品マックス。操作TMP:	2.1バー
使用法:	地表水、海水、飲料水	adavantage:	大きなフラックス

DuPont™ SFP-2880 UF Membrane: Advanced Water Purification for Industrial Applications

Product Overview

Engineered for excellence, the DuPont™ SFP-2880 ultrafiltration membrane represents cutting-edge water treatment technology. This premium-grade membrane utilizes state-of-the-art hollow fiber design to achieve exceptional filtration performance, effectively removing contaminants including pathogens, colloids, and particulate matter.

Specifically developed for demanding industrial environments, it serves as an ideal pretreatment solution for reverse osmosis systems and enables efficient wastewater recycling. The membrane demonstrates outstanding chemical compatibility and mechanical durability, ensuring stable operation under challenging conditions.

Key Features

Advanced Filtration Performance: Removes bacteria, viruses, and colloids with high efficiency; achieves filtrate turbidity below 0.1 NTU and SDI under 2.5; ideal protection for reverse osmosis systems
Engineered Durability: Chemical-resistant PVDF membrane withstands extreme pH conditions; U-PVC housing eliminates need for pressure vessels; operating temperature range supports global deployments
High-Efficiency Design: Industry-leading membrane area enables high flow rates; outside-in flow handles high solids loading; reduced backwash frequency lowers water consumption
Operational Reliability: Consistent performance in municipal and industrial settings; minimal maintenance requirements; compatible with automated control systems

Technical Specifications

Attribute	Value
UF Module Flux Range	40–90 LMH (24–53 gfd) at 25°C
Flow Rate per Module	2.0–6.9 m³/hr (8.8–30.4 gpm)
UF Module Temperature Limits	1–40°C (34–104°F)
UF Module Max Operating TMP	2.1 bar (30.5 psi)
Chemical Tolerance	Withstands up to 2,000 mg/L NaOCl
Membrane Area	77m²
Membrane Type	Industrial Grade Ultrafiltration Membrane Components

Product Specifications

Model	Type	Part #	Membrane Area (m²/ft²)	Volume (Liters/Gallons)	Weight (Kg/lbs)
SFP-2880	Pretreatment	280934	77 / 829	39 / 10.3	61 / 135 (empty), 100 / 220 (water filled)
SFD-2880	NSF/ANSI 61 Drinking water	324169	77 / 829	39 / 10.3	61 / 135 (empty), 100 / 220 (water filled)

Operating Parameters

Parameter	SI Units	US Units
Filtrate Flux @ 25ºC	40-120 l/m²/hr	24-70 gfd
Flow range	3.1-9.3 m³/hr	13.6 - 40.9 gpm
Temperature	1-40ºC	34-104ºF
Max. inlet module pressure (@ 20ºC)	6.25 bar	93.75 psi
Max. operating TMP	2.1 bar	30 psi
Max operating air scour flow	12 nm³/hr	7.1 scfm
Max backwash pressure	2.5 bar	36 psi
Operating pH	2-11

Important: If operating limits and guidelines given in this bulletin are not strictly followed, the limited warranty will be null and void. To prevent biological growth during system shutdowns, it is recommended that preservative solution be injected into the membrane modules.
